Miele S 700 series Operations Instructions

Operating instructionsVacuum cleanersS 700 seriesTo avoid the risk of accidents or damageto the appliance, it is essential to read theseinstructions b

Attaching the suction hose^Insert the hose connector into thesocket until it clicks into position.Removing the suction hosefrom the cleaner^ Press the

Your vacuum cleaner is fitted with oneof the following suction tubes,depending on model:–Connecting tubes–2-part telescopic tubeConnecting the suction

Fitting the standard floorhead^Push the suction tube into thefloorhead and turn it clockwise oranti-clockwise until it clicks intoposition.^To release

Other tools, in addition to thefloorhead(s), are supplied with thevacuum cleaner to help deal withvarious types of cleaning.a Crevice nozzleb Dusting

The different tools can either be fitted tothe hand piece or to the suction tube,as required.Standard floorheadFor general use and also for vacuumings

Dusting brushFor cleaning skirting boards, ornate orcarved articles, etc.The head of the dusting brush can beswivelled to attain the best cleaningposi

Mains cableUnwinding the cable^Pull out the mains cable to therequired length (max. approx. 6.5 m).Warning: If vacuuming for longerthan 30 minutes, th

Adjusting the suction powerThe suction power can be regulated tosuit the type of flooring. The higher thewattage, the more powerful the suction.Reduci

Parking systemA parking system has been designedfor conveniently parking the vacuumcleaner during pauses.^Slot the floorhead into the parkingattachmen

Warning: Always disconnect thevacuum cleaner from the electricalsupply for maintenance work and forcleaning. Switch off at the wallsocket and remove t

Caring for the environmentDescription of the applianceWarning and Safety instructionsPreparing for useAccessories suppliedUsing the accessories suppli

When to change the dustbagChange the dustbag when the colourmarker in the dustbag change indicatorfills the display, or sooner if it is nolonger effec

Replacing the dustbag^Press the release button for the dustcompartment lid and raise the lid asfar as it will go.^To remove the dustbag, hold the bagb

When to change the exhaustfilterDepending on the model, your vacuumcleaner will be fitted as standard withone of the following exhaust filters:a a Sup

Replacing the Super Air CleanfilterDo not use more than one exhaustfilter at a time.^Open the dust compartment lid.^Release the filter grille and rais

Replacing an Active Air Cleanfilter or an Active HEPA filterDo not use more than one exhaustfilter at a time.^Open the dust compartment lid.^Release t

When to change the dustcompartment filter (for motorprotection)Replace this filter every time you start anew packet of dustbags.A dust compartment fil

When to change the threadliftersThe thread lifters on the suction inlet tothe floorhead and the upholstery nozzlecan be replaced.Check them from time

Warning: Always disconnect thevacuum cleaner from the electricitysupply for maintenance work and forcleaning. Switch off at the wallsocket and remove

The vacuum cleaner switches offautomatically.A temperature limiter switches thevacuum cleaner off automatically if itgets too hot.This can occur if, f

Miele accessories includingfloorheads, filters and dustbags areavailable to order from your localMiele retailer, the Miele Spare PartsDepartment or vi

Disposal of packing materialThe transport and protective packinghas been selected from materials whichare environmentally friendly for disposaland can

ALLERGOTEC -3 floorheadThe level of cleanliness of the floorshows in a colour "traffic light" displaywhen vacuuming. The ALLERGOTECfloorhead

Universal brushFor dusting books, shelves, etc.Dusting brush with natural bristlesThis brush is suitable for particularlydelicate objects.Radiator bru

Mattress nozzleFor cleaning upholstery, mattresses,cushions, curtains, covers etc.Crevice nozzle (300 mm)For cleaning in folds, crevices orcorners.Hos

Hygiene seal with active charcoalThis prevents dust and odours fromescaping when the suction hose isremoved for transportation or storage.It can be se

Active Air Clean filterA special active charcoal filter, whichremoves odours coming from the dirt inthe dustbag, keeping unpleasantlingering smells to

All electrical work should be carried outby a suitably qualified and competentperson in strict accordance with currentnational and local safety regula

Alteration rights reserved / (710-718) - 1508M.-Nr. 07 316 630 / 00

Description of the appliance4

a Hand pieceb Air inlet valvec Release buttond Telescopic suction tube*e Telescopic tube release button*f Dust compartment release buttong Dust compar

This vacuum cleaner meets statutorysafety requirements. Improper usecan, however, lead to personal injuryand material damage.To avoid the risk of acci

Technical safety~Ensure that the connection data onthe data plate (voltage and frequency)match the mains electricity supply. It isessential that they

Correct use~To avoid the risk of damage, do notuse the vacuum cleaner without thedustbag, dust compartment filter andexhaust filter in place. Otherwis

AccessoriesMiele accessories includingfloorheads, filters and dustbags areavailable to order from your Mieleretailer, the Miele Spare PartsDepartment
